Applications
Swimming Pools
Pool sand and glass-clear filtration for commercial, hotel and public pools.
Specifying note
0.4–0.8 mm is the standard pool grade. Replace every 3–5 years — channelling from cemented media is the usual cause of persistent cloudiness.
Design parameters
- Filtration rate
- 30 – 50 m/h
- Replacement interval
- 3 – 5 years
- Sand charge
- ≈ 1,500 kg per m³ of bed
Typical bed configuration
| Layer | Media | Gradation | Depth |
|---|---|---|---|
| Filtration layer | Silica filter sand | 0.4 – 0.8 mm | 600 – 800 mm |
| Support layer | Support gravel | 2 – 4 mm | 50 – 100 mm |
- Layer
- Filtration layer
- Media
- Silica filter sand
- Gradation
- 0.4 – 0.8 mm
- Depth
- 600 – 800 mm
- Layer
- Support layer
- Media
- Support gravel
- Gradation
- 2 – 4 mm
- Depth
- 50 – 100 mm
A starting point, not a design. Final layer depths follow from vessel diameter, design filtration rate and target effluent quality.
